art deco masterpiece

a die image of a logic chip with bold purple traces on a green substrate
alt text
a die image of a logic chip with bold purple traces on a green substrate
but actually, it's the die shot of a logic chip that I turned on its side.

source: Ti 54LS153 - Dual 4→1 Data Selectors/Multiplexers : weekend die-shot : ZeptoBars — https://zeptobars.com/en...

datasheet: https://www.ti.com/lit...
